LUMATEK 230V CMH ballast + bulb Kits
LUMATEK CMH 315W Kit includes Lumatek 315W CMH electronic ballast and Lumatek 315W CMH bulb (Agro 3100K).
The 315W CMH pulse-start lamp is produced using high-grade ceramic arc tube technology and specific horticultural gas blend that creates optimal spectral output for vigorous plant growth. The CMH technology provides high energy PAR/PPF levels with low heat at full spectrum, which is closer to sunlight and produces healthier plant growth and results in larger yields. With a CRI (Colour Rendering Index) of >90%, CMH is perfect for growing high quality crops for essential oil extraction.
Thehe PCA ceramic arc tube permits the bulb to operate at higher internal temperatures increasing colour rendering, output and efficiency. PCA resists interaction with the chemicals inside the tube which stabilises the chemical mix over the life-span of the bulb, thereby improving colour consistency and PAR/PPF level maintenance. Pulse-start technology enables faster start up & restrike time, longer lamp life-span and increased lumen maintenance. Lumatek 315W CMH (Ceramic Metal Halide also known as CDM/LEC) bulbs are available in 4200K Daylight and 3100K Agro versions.
The reliable 315W CMH digital ballast uses square wave technology to efficiently power and operate 315W CMH bulbs. For safety the ballast uses full circuit protection including open/short circuit, over temperature, over/low voltage, end of lamp life/rectification and EMI suppression. The ballast is dimmable for optimum control.
| Variant | Voltage (V) | Current (A) | Lamp Base/Cap | Power factor | Dimming | Controllable | Dimming range | IP Rating | Humidity tolerance | THD | Dimensions | Weight | Warranty | ID | Vendor ID | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 315W 230V - Daylight 4200K - Dimmable | 230 V | 1,4 A | E40 | >0,98 | Yes | Yes | 50% - 60% - 70% - 80% - 90% - 100% | IP20 | 90% | <10 % | 24,5 x 11,4 x 8,1 cm | 2.5 kg | 5 Years | CVG02397 | LUMK0004 | 479,70 € | |
| 315W 230V - Daylight 4200K - Dimmable & Controllable | 230 V | 1,4 A | E40 | >0,98 | Yes | Yes | 50% - 60% - 70% - 80% - 90% - 100% | IP20 | 90% | <10 % | 24,5 x 11,4 x 8,1 cm | 2.5 kg | 5 Years | CVG02398 | LUMCK002 | 498,20 € | |
| 315W 230V - AGRO 3100K - Dimmable | 230 V | 1,4 A | E40 | >0,98 | Yes | - | 50% - 60% - 70% - 80% - 90% - 100% | IP20 | 90% | <10 % | 24,5 x 11,4 x 8,1 cm | 2.5 kg | 5 Years | CVG02399 | LUMK0004 | 479,70 € | |
| 315W 230V - AGRO 3100K - Dimmable & Controllable | 230 V | 1,4 A | E40 | >0,98 | Yes | - | 50% - 60% - 70% - 80% - 90% - 100% | IP20 | 90% | <10 % | 24,5 x 11,4 x 8,1 cm | 2.5 kg | 5 Years | CVG02400 | LUMCK002 | 498,20 € | |
| 630W 230V DE - Daylight 4200K - Dimmable & Controllable | 230 V | 3,2 A | E40 | >0,97 | Yes | Yes | 80% - 90% - 100% | IP20 | 90% | <10 % | 32 x 11,4 x 8,1 cm | 3,8 Kg | 5 Years | CVG02402 | LUMCK007 | 701,10 € | |
| 630W 230V DE - AGRO 3100K - Dimmable & Controllable | 230 V | 3,2 A | E40 | >0,97 | Yes | Yes | 80% - 90% - 100% | IP20 | 90% | <10 % | 32 x 11,4 x 8,1 cm | 3,8 Kg | 5 Years | CVG02404 | LUMCK007 | 701,10 € |
